Cryo Bath Model No. BCB

We are one of the largest CRYO Temperature Bath Exporters and Suppliers in India. Cryobath is designed by good quality and fine range of quality accessories to match all the specific laboratory and process applications outer chamber is of mild steel and duly powder coated. Our product the Laboratory Cryobath has inner chamber made of SS 304. Foam in place puffed insulation improves temperature stability and energy efficiency. Cryo Bath which we provide is the latest in technology and highly user friendly

Features :
 Can thaw 12 FFP/Apheresis or plasma bags of any size.
 have two separate basket assemblies.
 built in fingers for securely holding the plasma bags.
 gives an alarm when the plasma bags are thawed, have deep thawing chamber with a stirrer, have a minutes, have a SS cover
Temperature Range : Temperature Range having 4 Deg to 50 Deg C
Insulation : PUF insulation for better power saving purposes.

Temp. Controller : PID (Programmable) Microprocessor Based Temperature Controller used for controlling 4°37° C ± 1o C accuracy: 0.1 Have audio visual over temperature alarm system.
Control panel : Controls to compromise fully automatic temperature Indicator cum PID (Progra.)Microprocessor Based Temperature Controller with PT – 100 Sensor, Temp. Recorder,
Compressor, fans, Alarm etc.
Cooling Unit : Kirloskar make Compressor, which is CFC Free.
Power Supply : 230 Volts, Single Phase 50HZ
Trays : No. of Trays 2  in S.S. for proper Storage of FFP/Apheresis or plasma bags.
Safety : Electronic safety device incorporated that will give audiovisual alarming case of power failure along with Voltage Stabilizer along with Low & High Voltage protector.

Technical Specification

  1. Model                                 : BCB
  2. Operating Temperature : +4°C
  3. Circulation                        : Submersible Pump
  4. Capacity                             : 12 Plasma Bags
  5. Cabinet                               : Cabinet on Castor Wheels
  6. Power Supply                    : 230V single Phase 50HzAc
